FS 16i/18i TA/TB, High-precision Contour Control function for Complex Lathe Additional Manual Page 11

Additional Manual
A-78395E
Edit
Apprv
ApprvApprv
Apprv.
..
.Desig
DesigDesig
Desig.
..
.
Sheet
Title
Draw
No.
10/75
Date
DateDate
Date
Design
DesignDesign
Design
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
•
••
•
Cancel
When a block containing no movement operation is specified together with the cutter
compensation cancel code (G40), a vector with a length equal to the offset value is created in
a direction perpendicular to the movement direction of the previous block. Cutter
compensation mode is canceled while this vector still remains. This vector is canceled when
the next move command is executed.
·
·
N6 G91 X100. Z100. ;
N7 G40
N8 X100. ;
·
·
If cutter compensation mode is canceled while a vector still remains and HPCC mode is
canceled before a move command is specified, the P/S alarm No.5013 is issued.
·
·
N6 G91 X100. Z100. ;
N7 G40
N8 G05 P0 ;
·
·
2.11 Cs contour control
Cs axis can be instructed in the HPCC mode.
•
••
•
Paremeter setting
Please set a parameter No.1602#5(G8S) to 1 in case of using Cs contour control in HPCC
mode.
•
••
•
Instruction form
The Reference point return of Cs axis can not be specified in HPCC mode. Please enter the
HPCC mode according to the following procedures when you use Cs axis in the HPCC mode.
(1) Turning on the Cs contour control mode.
(2) Reference point retiurn of Cs axis.
(3) Turning on the HPCC mode.
N6
N7 N8
The P/S alarm No. 5013 is issued.
02
02
