FS 16i/18i TA/TB, High-precision Contour Control function for Complex Lathe Additional Manual Page 50

Additional Manual
A-78395E
Edit
Apprv
ApprvApprv
Apprv.
..
.Desig
DesigDesig
Desig.
..
.
Sheet
Title
Draw
No.
49/75
Date
DateDate
Date
Design
DesignDesign
Design
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
2.17.2 Feedrate determination based on a feedrate difference along each axis
The speed is decelerated in the corner so that the speed change of each axis should not exceed
a permissible speed difference. The permissible speed difference is set by parameter No.8410.
•
••
•
Example
Suppose that the specified feedrate for the tool is 1,000 mm/min, and that the direction of tool
movement changes by 90 degrees (from along the X–axis to along the Y–axis). Suppose also
that an allowable feedrate difference of 500 mm/min is set. Then, the tool will decelerate as
shown below.
N2
N1 G01 G91 X100. F1000 ;
N2 Y100. ;
N1
Tool path when the tool
does not decelerate at
the corner
←
Tool path when the tool decelerates at the
corner
When the tool does not
decelerate at the corner
When the tool decelerates at
the corner
N1 N2
Time
N2
Time
Time
Feedrate
F1000
F500
Feedrate
along the
X–axis
F1000
F500
F1000
F500
Feedrate
Feedrate
Feedrate
along the
Y–axis
Feedrate along
the tangent to the
path
Fig. 2.17.1(a) Example of deceleration by deference of each axis feedrate
