FS 16i/18i TA/TB, High-precision Contour Control function for Complex Lathe Additional Manual Page 13

Additional Manual
A-78395E
Edit
Apprv
ApprvApprv
Apprv.
..
.Desig
DesigDesig
Desig.
..
.
Sheet
Title
Draw
No.
12/75
Date
DateDate
Date
Design
DesignDesign
Design
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
Table 2.12.3 (a)
Profile Portions having mainly
a small radius of
curvature
Portions having mainly
a large radius of
curvature
Example of machined
parts
Automobile parts Decorative parts, such
as body side moldings
Length of line segment Short Long
Resulting surfaces
produced using high–
precision contour
control
Smooth surface even
when machining is
performed exactly as
specified by a program
Uneven surfaces may
result when machining is
performed exactly as
specified by a program
Fig. 2.12.3(b) Example of uneven surfaces (polygon) resulting
from machining that precisely follows the line
segments.
In smooth interpolation mode, the CNC automatically determines, according to the program
command, whether an accurate figure is required, such as at corners, or a smooth figure is
required where the radius of curvature is large. If a block specifies a travel distance or
direction which differs greatly from that in the preceding block, smooth interpolation is not
performed for that block. Linear interpolation is performed exactly as specified by the
program command. Programming is thus very simple.
Note )
When the result of the automatic judgment of CNC is different
from the movement which the programmer intended, cancel a
smooth interpolation temporarily or change the instruction point
or the correspondence of the adjustment of the parameter etc. is
needed.
