FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
Item Specifications Remarks
Interpolation function
Positioning G00
Linear interpolation G01
Circular interpolation G02,G03
Helical interpolation Circular interpolation plus max. 2
axes linear interpolation
The option of helical interpolation is necessary.
Smooth interpolation G05.1 Q2 Only in the HPCC mode.
NURNS interpolation G06.2 Only in the HPCC mode.
Feed function
Feed per minute G94(G98)
Cutting feedrate clamp
Linear acceleration/deceleration after
cutting feed interpolation
This is an optional function.
Bell-shaped
acceleration/deceleration after cutting
feed interpolation
This is an optional function.
Feedrate override 0
254% 1% Step
2
nd
Feedrate override 0
254% 1% Step This is an optional function.
Linear acceleration/deceleration
before look ahead interpolation
Bell-shaped
acceleration/deceleration before look
ahead interpolation
Program input
Tape code EIA/ISO automatic recognition
Program format Word and address format
Control in/out
Optional block skip
Absolute/incremental programming G90/G91
Input unit 10 time multiply
Plane selection G17,G18,G19
Rotary axis roll-over
Manual absolute on and off FS15 specification
Programmable data input G10 The HPCC mode is automatically canceled once, and buffering
is stopped.
External sub program call M198 The HPCC mode is automatically canceled once, and buffering
is stopped.
Sub program call M98 The HPCC mode is automatically canceled once, and buffering
is stopped.
Circular interpolation by R
programming
Scaling G50,G51 Alarm (P/S5012) is generated if turned on or off of HPCC is
commanded in scaling mode(G51).
The scaling mirror image by a negative magnification instruction
cannot be done.
Coordinate system rotation G68,G69 Alarm (P/S5012) is generated if turned on or off of HPCC is
commanded in coordinate system rotation mode(G68).
Programmable mirror image G50.1,G51.1 Alarm (P/S5012) is generated if turned on or off of HPCC is
commanded in programmable mirror image mode(G51.1).
