FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
4
Signal
HPCC mode signal
MHPCC (F066#6)
[Classification]
Output signal
[Function]
Indicates that the system is set to high–precision contour control mode (HPCC mode).
[Output condition]
The signal is set to 1 if G05 P10000 (HPCC mode ON) is specified in a program. The signal
is set to 0 if G05 P0 is specified in a program or if HPCC mode is canceled by a reset.
HPCC operation signal
EXHPCC (F066#7)
[Classification]
Output signal
[Function]
Indicates that the system is operating in high–precision contour control mode (HPCC
operation is in progress).
[Output condition]
The signal is set to 1 if G05 P10000 (HPCC mode ON) is specified in a program and if
specifiable data of except G00 of Type-A(*1) and auxiliary function is executed.
The signal is set to 0 when:
(1) Automatic operation is halted.
(2) Automatic operation is stopped.
(3) HPCC mode is canceled.
(4) While executing the G00 instruction of type-A.
(5) While executing the block with auxiliary function (M code, S code, or second auxiliary
function).
(6) While executing the block with subprogram call.
(7) When either address U, V, W, or H is specified in G code system B or C.
(8) When the axis which HPCC is not effective(*2) is instructed.
When this signal is "0", the blinking display of "HPCC" under the right of the screen is not
done.
(*1) Please refer to section 2.7.
(*2) Please refer to description of parameter No.7510 (section 3.3).
Siganl addresses
#7 #6 #5 #4 #3 #2 #1 #0
F066 EXHPCC MHPCC
