3.6 Smooth interpolation
#7 #6 #5 #4 #3 #2 #1 #0
8485 CDS
[Data type]
Bit
ICK
In HPCC mode, smooth interpolation is:
0: Disabled
1: Enabled
8486 Maximum travel distance of a block where smooth interpolation is applied
[Data type]
Two-word
[Unit of data]
Increment
system
IS-B IS-C Unit of
data
mm input 0.001 0.0001 mm
inch input 0.0001 0.00001 inch
[Valid data range]
0 to 99999999
This parameter specifies a block length used as a reference to decide whether to apply smooth
interpolation. If the line specified in a block is longer than the value set in the parameter,
smooth interpolation will not be applied to that block. This parameter can be used, for
example, to specify the maximum line length of a folded line to which a metal die workpiece
is approximated with some tolerance.
8487 Angle by which smooth interpolation is turned off
[Data type]
Word
[Unit of data]
0.1°
[Valid data range]
0 to 32767
This parameter specifies an angle to judge whether to smooth interpolation shoud be
executed. When the block with larger angle difference than this value appears, a smooth
interpolation is turned off once.
When 0 is set, it is considered 10 degrees.
8490 Minimum travel distance of a block where smooth interpolation is applied
[Data type]
Two-word
[Unit of data]
Increment
system
IS-B IS-C Unit of
data
mm input 0.001 0.0001 mm
inch input 0.0001 0.00001 inch
[Valid data range]
0 to 99999999
This parameter specifies a block length used as a reference to decide whether to apply smooth
interpolation. If the line specified in a block is shorter than the value set in the parameter,
smooth interpolation will not be applied to that block.
