FS 16i/18i TA/TB, High-precision Contour Control function for Complex Lathe Additional Manual Page 63

Additional Manual
A-78395E
Edit
Apprv
ApprvApprv
Apprv.
..
.Desig
DesigDesig
Desig.
..
.
Sheet
Title
Draw
No.
62/75
Date
DateDate
Date
Design
DesignDesign
Design
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
3.4 Acceleration/deceleration after interpolation
#7 #6 #5 #4 #3 #2 #1 #0
1602 LS2
[Data type]
Bit
LS2
Acceleration/deceleration after interpolation for cutting feed in the high precision contour
control mode (HPCC mode) is:
0: Not used. (Exponential acceleration/deceleration)
1: Used. (The function for linear acceleration/deceleration after interpolation
for cutting feed
is required.)
1768 Time constant for linear acceleration/deceleration during cutting feed in
HPCC mode
[Data type]
Word
[Unit of data]
msec
[Valid data range]
RI2 RI1 RI0 Data range
0 0 1 2 to 128
The range of data is different according to the command of (RI0,RI1,RI2) of parameter
No.8480.
3.5 Cutter compemsation C
#7 #6 #5 #4 #3 #2 #1 #0
5000 SBK
[Data type]
Bit
SBK
An internally created block for cutter compensation C:
0: Does not cause a single block stop.
1: Cause a single block stop.
#7 #6 #5 #4 #3 #2 #1 #0
5003 BCK ICK
[Data type]
Bit
ICK
In HPCC mode, when cutter compensation C interference check is:
0: Done
1: Not done
BCK
In HPCC mode, when cutter compensation C interference check determines that the
programmed move direction differs from the offset move direction by between 90 and 270
degrees:
0: An alarm is issued.
1: No alarm is issued.
