FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
2
Operation
2.1 Format
The high-precision contour control mode can be turned on or off by following instructions.
The character of "HPCC" is blinking displayed under the right of the screen in the high-
precision contour control mode.
G05 P10000 : Start high-precision contour control mode
G05 P0 : End high-precision contour control mode
Please command G05 alone.
The mode used to perform high–precision contour control is called HPCC mode.
2.2 Condition that HPCC is permitted
Before G05P10000 can be specified, the following modal values must be set. If they are not
set, the P/S alarm No.5012 is issued.
G code Meaning
G13.1 Cancels polar coordinate interpolation.
G40 Cancels tool nose radius compensation.
G50 Cancels scaling.
G50.1 Cancels the programmable mirror image function.
G50.2 Cancels Polygonal turning
G64 Cutting mode
G69.1 Cancels coordinate conversion.
G80 Cancels canned cycles.
G98[G94] Feed per minute
G97 Cancels constant surface speed control.
2.3 Commands that HPCC is cancelled temporarily
The HPCC mode is automatically canceled once when the undermentioned instruction is done
in the HPCC mode, and buffering is stopped. Moreover, the HPCC operating signal
EXHPCC becomes "0".
• Positioning (G00) of TYPE-A(*1)
• Auxiliary function (M command)
• The second auxiliary function
• Multiple M commands in a same block
• Spindle function (S command)
(*1) Please refer to section 2.7.
Previous page
Next page
