FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
7
The function table which can be used by a high-precision contour
control
The function excluding this cannot be used.
Item Specifications Remarks
Controlled axis
Controlled axis 2 axes
Controlled path 1 path
Simultaneously controlled axes 2 axes
Controlled axis expansion(total) Max. 8 axes
Simultaneously controlled axes
expansion(total)
Max. 6 axes
Axis control by PMC The axis of HPCC cannot command by PMC in HPCC mode
Angular axis control, Arbitrary
angular axis control
The feedrate control is done in the program coordinate system.
Cs contouring control In the instruction in Cs axis in the HPCC mode, the advanced
feedforward control is canceled once.
Simple spindle synchronous control Only for 1 path system
Axis recomposition Only for 2 path system
Synchronous control can not be used. Only Cs axis is possible
the composite control.
Axis name In case of G code system A,
basic 2 axes are X and Z,
additional axes are optional from
Y,A,B and C.
In case of G code system A,
basic 2 axes are X and Z,
additional axes are optional from
Y,U,V,W,A,B and C.
Least input increment 0.001mm,0.001deg,0.0001inch
increment system 1/10 0.0001mm,0.0001deg,0.00001inch
Inch/metric conversion The inch/metric mode cannot be switched in the HPCC mode.
Interlock All axes, each axis
Machine lock All axes, each axis The each axis machine lock signal cannot be changed in the
HPCC mode.
Emergency stop
Stored stroke check 1
Stored stroke check 2 G22/G23 can not be commanded in the HPCC mode. (Become
P/S5000 alarm) Please instruct them before the HPCC is
turned on.
Mirror image The state cannot be changed in the HPCC mode.
Backlash compensation for each
rapid traverse and cutting feed
Manual handle interruption Please set parameter 7100#2(IHD) to “1” when the angular axis
control or arbitrary angular axis control is used..
Operation
Automatic operation
Cycle start / feed hold
Program stop / Program end
Reset
Dry run
Single block
Previous page
Next page
