FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
3.2 Automatic feedrate control function
8410 Allowable velocity difference in velocity determination considering the
velocity difference at corners
[Data type]
Word axis
[Unit of data, Valid data range]
Valid data range
Increment system Unit of data
IS-B IS-C
Millimeter machine 1 mm/min 10—60000 1--6000
Inch machine 0.1 inch/min 10—60000 1--6000
Rotation axis 1 deg/min 10—60000 1--6000
If zero is specified for all axes, the machine does not decelerate at corners.
When the function for determining the velocity considering the velocity difference at corners is used, the
system calculates the feedrate whereby a change in the velocity element of each axis does not exceed this
parameter value at the interface between blocks. Then the machine decelerates using acceleration/
deceleration before interpolation.
#7 #6 #5 #4 #3 #2 #1 #0
8451 NOF ZAG USE
[Data type]
Bit
USE
Automatic velocity control is:
0 : Not applied.
1 : Applied.
ZAG
The velocity is:
0: Not determined according to the angle at which the machine descends along the
Z–axis.
1: Determined according to the angle at which the machine descends along the
Z–axis.
NOF
In a block where automatic velocity control is validated, the F command is:
0 : Validated.
1 : Ignored.
(Maximum speed of automatic feedrate control set by parameter No. 8465 is used for
command speed in spite of F command)
8452 Range of velocity fluctuation to be ignored
[Data type]
Byte
[Unit of data]
%
[Valid data range]
0 to 100 (Standard setting: 10)
