FS 16i/18i TA/TB, High-precision Contour Control function for Complex Lathe Additional Manual Page 76

Additional Manual
A-78395E
Edit
Apprv
ApprvApprv
Apprv.
..
.Desig
DesigDesig
Desig.
..
.
Sheet
Title
Draw
No.
75/75
Date
DateDate
Date
Design
DesignDesign
Design
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
Item Specifications Remarks
Auxiliary/Spindle speed function
Auxiliary function It is necessary to set “1” in parameter No.8403#1 (MSU). The
HPCC mode is automatically canceled once when instructing in
the auxiliary function, and buffering is stopped.
2
nd
auxiliary function It is necessary to set “1” in parameter No.8403#1 (MSU). The
HPCC mode is automatically canceled once when instructing in
the 2
nd
auxiliary function, and buffering is stopped.
Multiple command of auxiliary
function
Max.3 It is necessary to set “1” in parameter No.8403#1 (MSU). The
HPCC mode is automatically canceled once when instructing in
the auxiliary function, and buffering is stopped.
Spindle speed function It is necessary to set “1” in parameter No.8403#1 (MSU). The
HPCC mode is automatically canceled once when instructing in
the spindle speed function, and buffering is stopped.
Tool function/Tool compensation
Cutter compensation C G39,G40,G41,G42 If the instruction that the HPCC mode is automatically canceled
once (auxiliary function etc.) is commanded, the vector is held
because Buffering is stopped
