FS 16i/18i TA/TB, High-precision Contour Control function for Complex Lathe Additional Manual Page 67

Additional Manual
A-78395E
Edit
Apprv
ApprvApprv
Apprv.
..
.Desig
DesigDesig
Desig.
..
.
Sheet
Title
Draw
No.
66/75
Date
DateDate
Date
Design
DesignDesign
Design
Descri
p
tion
Descri
p
tionDescri
p
tion
Descri
p
tion
Date
DateDate
Date
FANUC Series 16
i
/18
i
-TA/TB
Specifications of High-Precision Contour
Control forComplex Lathe
2001.02.14 A.Fukumoto
02 2001.10.04
Description of Cs axis and rotary axis are added.
5411 Magnification used when scaling magnification is not specified
[Data type]
Two-word
[Unit of data]
0.001 or 0.00001 times (Selected using SCR, #7 of parameter No.5400)
[Valid data range]
1 to 999999
This parameter sets the scaling magnification. This setting value is used when a scaling
magnification (P) is not specified in the program.
NOTE)
Parameter No.5421 becomes valid when scaling for every axis is valid. (XSC,
#6 of parameter No.5400 is “1”.)
5421 Scaling magnification for each axis
[Data type]
Two-word axis
[Unit of data]
0.001 or 0.00001 times (Selected using SCR, #7 of parameter No.5400)
[Valid data range]
1 to 999999
This parameter sets the scaling magnification for each axis.
3.8 The other parameter
#7 #6 #5 #4 #3 #2 #1 #0
8403 SG0 MSU
[Data type]
Bit
MSU
When G00, or an M, S, or B code is specified in HPCC mode:
0: An alarm is issued.
1: The CNC executes the command.
SG0
When G00 is specified in HPCC mode:
0: The setting of bit 1 (MSU) of parameter No. 8403 is followed.
1: Executed in HPCC mode.
NOTE)
Please set (STG) of parameter No.8404#0 in “1” when you set “1” in this
parameter.
#7 #6 #5 #4 #3 #2 #1 #0
8404 EIL STG
[Data type]
Bit
STG
Please set the same value as parameter 8403#7(SG0).
EIL
In HPCC mode, each axis inter-lock is:
0: Not effective.
1: Effective.
