Alarm and message
Number Message Description
10 IMPROPER G–CODE
·
There is no option of the corresponding function.
·
An unusable G code G is specified.
·
The following instructions are commanded in G00
mode.
G50 / G51 (Scaling)
G68 / G69 (Coordinate system rotation)
G50.1 / G51.1 (Programmable mirror image)
G05.1 Q2 (Smooth interpolation)
G06.2 (NURBS interpolation)
·
G05 P10000 was commanded in in the MDI mode.
5000 ILLEGAL COMMAND
CODE (HPCC)
·
The instruction (G code and T code, etc.) which was
not able to be used in HPCC mode was commanded.
·
The instruction for an axis with parameter No.1006#3
(DIA) and No.8414#0 (RRD) is set “1” is
commanded.
·
The interrupt type custom macro was started in
HPCC mode.
·
The instruction that the EXHPCC signal becomes 0 in
either of scaling, the coordinate rotation or the
programmable mirror image mode was commanded.
5003 ILLEGAL PARAMETER
(HPCC)
The parameter setting is incorrect.
5004 HPCC NOT READY High–precision contour control is not ready.
5006 TOO MANY WORD IN
ONE BLOCK
The number of words specified in a block exceeded 26
in the HPCC
5012 G05 P10000 ILLEGAL
START UP
G05 P10000 has been specified in a mode from which
HPCC mode cannot be entered.
5013 HPCC:CRC OFS REMAIN
AT CANCEL
·
G05 P0 was commanded with in the G41/G42 mode
or the amount of the offset remained.
·
G05 P0 was instructed in in G51.1 (programmable
mirror image) mode.
5115 SPL:ERROR In the NURBS interpolation,
·
There is an error in the specification of the rank.
·
No knot is specified.
·
The knot specification has an error.
·
The number of axes exceeds the limits.
·
Other program errors
5116 SPL:ERROR In the NURBS interpolation,
·
There is a program error in a block under look–ahead
control.
·
Monotone increasing of knots is not observed.
·
A mode that cannot be used together is specified.
5117 SPL:ERROR The first control point of NURBS is incorrect.
5118 SPL:ERROR After manual intervention with manual absolute mode
set to on, NURBS interpolation was restarted.
5196 ILLEGAL OPERATION
(HPCC)
The control axis detaching was done in HPCC mode.
After the block being executed now ends, this alarm is
generated if the control axis detaching is done in
HPCC mode.
5313 G05 P0 COMMANDED IN
G68.1/G51
G05 P0 was commanded in the coordinate system
rotation or in the scaling mode.
5314 SMOOTH IPL ERROR 1 The mistake is found in the format of smooth
interpolation block.
