11. PROGRAM COMMAND
B--63003EN--1/02
996
NOTE
1 Specify a rotation axis as the index table indexing axis. (Set
1 in the ROTx bit (bit 0 of parameter No. 1006).)
2 The servo off signal for the index table indexing axis is
invalid.
3 Single direction positioning (G60) cannot be specified.
4 While the index table is being positioned, input signals that
reset the CNC, such as *ESP (emergency stop), ERS
(external reset), and RRW (reset & rewind), are functional.
When reset is applied to the CNC, this operation stops.
Further, if *SP (automatic operation stop signal) turns to “0”,
axis movement is stopped and the equipment enters the
automatic operation stop state.
If a stop at an any position is not suitable for the machine,
appropriate processing is required on the machine.
5 If a reset occurs while the system is awaiting the completion
of clamping or unclamping, the clamp or unclamp signal is
cleared. The CNC exits from the completion wait status.
6 Manual operation of jog feed, incremental feed and handle
feed cannot be used with the B axis, but manual reference
position return is possible. If reset is applied during the
movement of B axis, the manual reference position return
operation should be performed.
7 No movement can be performed by automatic return from
the reference position (G29), return to the second reference
position (G30), or selection of the machine coordinate
system (G53).
8 Only the fourth axis can be used as the index table indexing
axis.
Series
16i/160i/18i/180i
OPERATOR’S MANUAL
(For Machining Center)
(B--63014EN)
II.13.11 Index table indexing function
Series 21i/210i OPERATOR’S MANUAL
(For Machining Center)
(B--63094EN)
II.13.5 Index table indexing function
Note
Reference Item
