B--63003EN--1/02
9. SPINDLE SPEED FUNCTION
793
3930 Number of servo axis that interpolates with Cs contour control
[Data type] Byte
[Valid data range] 0to8
Set the number of servo axis that interpolates with Cs contour control axis
(4th group)
NOTE
When there is no servo axis or less than four servo axes that
interpolates with Cs contour control axis, set this parameter
to 0.
3931 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (High gear)
3932 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Medium high gear)
3933 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Medium low gear)
3934 Loop gain of the servo axis that interpolates with Cs contour control axis during
interpolation (Low gear)
[Data type] Word axis
[Unitofdata] 0.01 sec
-- 1
[Valid data range] 0 to 32767
Set the servo loop gain of the servo axis that interpolates with Cs contour
control axis on each spindle gear (4th group)
3940 Number of servo axis that interpolates with Cs contour control
[Data type] Byte axis
[Valid data range] 0to8
Set the number of servo axis that interpolates with Cs contour control axis
(5th group)
NOTE
When there is no servo axis or less than five servo axes that
interpolates with Cs contour control axis, set this parameter
to 0.
