#7 #6 #5 #4 #3 #2 #1 #0
15008 RMP EGE DCW SOC TAL GPC MST
[Data type] Bit
MST
0: When a reference displacement amount is specified with a plus
sign (+) in the trace command, the nozzle approaches the
workpiece. When a reference displacement amount is specified
with a minus sign (-), the nozzle moves away from the
workpiece.
1: When a reference displacement amount is specified with a plus
sign (+) in the trace command, the nozzle moves away from the
workpiece. When a reference displacement amount is specified
with a minus sign (-), the nozzle approaches the workpiece.
GPC
0: Exercises tracing control according to the reference displacement
amount.
1: Exercises tracing control according to the gap amount (distance
between the nozzle and workpiece).
TAL
0: Invalidates the "out-of-tracing-range alarm" when the trace check
mode signal (G225#2 TRCKM) is set to "1."
1: Invalidates both of the "out-of-tracing-range alarm" and "excess
tracing displacement alarm" when the trace check mode signal
(G225#2 TRCKM) is set to "1."
SOC
0: Uses the reference displacement amount for piercing as that for
tracing control not during processing when the processing
condition setting function is used.
1: Uses the reference displacement amount for piercing as that for
tracing control only during piercing when the processing
condition setting function is used.
DCW
0: Does not display the DCV, DCI, and DCW values on the
diagnostic display.
1: Displays the DCV, DCI, and DCW values on the diagnostic
display.
EGE
0: Disables the automatic aging function.
1: Enables the automatic aging function.
RMP
0: The step function uses only the up/down step distances to
measure the travel distance.
1: The step function uses the up/down step distances and feedrate
setting to measure the travel distance.
