3.INSTALLATION B-70315EN/02
- 62 -
(b) If not placing the cable in the duct
If not placing the power cable in the duct between the
power board and the laser oscillator, you can use a
heavy-duty power cord cable.
C1000-E
OSC Recommendation
Hitachi Cable : 600V 2PNCT
Cross Section
22mm
89A
Diameter
28mm
Current
LAPP : OLFLEX 100 25mm
25.4mm
93A
C2000-E
Hitachi Cable : 600V 2PNCT 38mm
126A
34mm
LAPP : OLFLEX 100 50mm
34.5mm
146A
C4000-E
C5000-E
Hitachi Cable : 600V 2PNCT 100mm
244A*
24mm
LAPP : OLFLEX FD-90 120mm
23.8mm
254A*
C6000-E
Hitachi Cable : 600V 2PNCT 150mm
300A*
26mm
LAPP : OLFLEX FD-90 185mm
28.9mm
332A*
4 Core
Sheathed
Portable
1 piece
Cross Section Diameter
Type Layout
1 Core
Sheathed
Portable
4 pieces
Cross Section
Diameter
Hitachi Cable : 600V 2PNCT
LAPP : OLFLEX FD-90
80mm
211A*
24mm
95mm
23.8mm
217A*
* This value is a allowable current of single wire in ambient
air temperature 40 ℃ multiplied by stacked wiring
adjustment factor 0.7.
(c) Recommended cable suppliers
Hitachi Cable : Hitachi Cable, Ltd.
Furukawa : The Furukawa electric Co., Ltd.
LAPP : U.I. Lapp GmbH
(d) Crimp terminal connectors
Use the crimp terminal connectors in C1000-E, C5000-E,
and C6000-E.
* JST=JAPAN SOLDERLESS TERMINAL MFG Co., Ltd.
** Attach the crimp terminal to the cable after passing the
cable through the cable service entrance.
OSC Cable size Manufacturer
Crimp terminal
part#
Cramping
tool part#
C1000-E 22 to 25 JST* 22-S8 YA-5
100 to 117.2 JST* CB100-S8
C5000-E
117.2 to 152.05 JST* CB150-S8**
125 to 152.05 JST* 150-10**
152.05 to 192.6 JST* 180-10**
C6000-E
192.6 to 242.27 JST* CB200-S10**
YF-1
