B-63423EN/02 USER PROGRAM 14. USER WINDOW PROGRAMS

-93-

14.4 MEMORY STORAGE AND CHANGING TOOLS

1) Memory storage tool

The G code (G235) is provided to store input data on the NC

tape memory. When the MDI [INSERT] key is pushed, the

custom macro creates process data and stores it on the NC tape

memory. When the following input data is set and G235 is

specified, the data can be stored on the NC tape memory:

Variable Item name Variable Item name

+0 Machining type . . . . . .

+1 Reserved +66 Address of input data 22

+2 Reserved +67 Attribute of input data 22

+3 Address of input data 1 +68 Argument of input data 22

+4 Attribute of input data 1 +69 Address of input data 23

+5 Argument of input data 1 +70 Attribute of input data 23

+6 Address of input data 2 +71 Argument of input data 23

+7 Attribute of input data 2 +72 Address of input data 24

+8 Argument of input data 2 +73 Attribute of input data 24

. . . . . . +74 Attribute of input data 24

NOTE

1 For more information about input data, see Section

8.1, "Data Attribute."

2 The starting variable number is specified with

parameter No. 9102. The standard value is #6070.

3 The value set for the machining type (+0) should be

the same as that for parameter No. 9112. If the

value is different from the parameter value, the user

window does not open for changing data.

4 When G325 is specified, process data is stored on

the NC tape memory and the user window closes.

Example in which 400 is set for parameter No. 9112 and X123.456 is

output

#6070=400; .............G400

#6073=24; ...............Address X

#6074=4051; ...........Decimal fraction data

#6075=123.456; ......Data to be stored

G235;.......................NC memory storage specification

G400X123.456;

<INSERT

INSERTINSERT

INSERT> (Memory storage)

Input data

setting
