5. COMMENT ON A MANUAL GUIDE SCREEN

USER PROGRAM B-63423EN/02

-16-

5.1 COMMENT IN A TITLE BAR

O700n ;

N9999 (Alphanumeric letters for Title Bar comment) ;

Maximum 50 ch.

NOTE

1. This user program number O700n is specified to

“Macro program number for displaying System

Comment”, which is specified in Start-up macro

program.

2. By selecting "n" in O700n, Displaying language can

be automatically changed. And, in the similar

description coming out hereafter, this "n" has same

meaning.

n=1 : English

2 : Japanese

3 : German

4 : French

5 : Italian

6 : Spanish

3. Number described in ( ) means the maximum

character number available for the comment.

Sample for English)

O7001 ;

N9999(' MANUAL GUIDE') ;

Title Bar of MANUAL GUIDE

MANUAL GUIDE
