3. CREATING LOADING FILES

USER PROGRAM B-63423EN/02

-8-

<10>RESULT.SRC

Source file for a sample macro program for displaying

measurement results (required when the measurement cycle

option is provided)

<11>MBJ41_U1.LNK

Sample link control file used to create user module 1 when

the measurement cycle option is provided

NOTE

1 Macro programs for measurement cycles must only

be used with the measurement cycle option, which

should be purchased separately. Without the

option, the programs do not operate normally if they

are linked.

3) Disk 3:

<1> F16IMP1M.MEX

Object file used to create a load module file for the macro

program section of the MANUAL GUIDE (the load module

file is hereinafter referred to as "user module 1")

<2> F16IMP2M.MEX

Object file used to create a load module file for the macro

program section created by the MTB (the load module file

is hereinafter referred to as "user module 2")

<3> STARTUP.SRC

Source file for a macro program that defines the screen

layout

<4> PROC*.SRC

Source file for a macro program that defines the process

data

<5> MACROSTR.SRC, STRING*.SRC

Source files for macro programs that define the strings

<6> FIG*.SRC

Source file for a macro program for guidance drawing

figures

<7> CHECK*.SRC

Source file for a macro program for checking input

completion

<8> COMMON.SRC, HOLE.SRC, H_PTN.SRC, FACE.SRC,

SIDE.SRC, POCKET.SRC, CONTOUR.SRC

Source programs for macro programs for machining macros

Contents Summary of MANUAL GUIDE (for Milling) Programming manual
