B-63423EN/02 USER PROGRAM 15. DISPLAYING USER-SPECIFIED STRINGS

-103-

15.1 EXAMPLE OF DEFINING THE TITLE AS A SEPARATE

PROGRAM

1) For parameter No. 9170, specify the program number of the

FANUC standard macro that has the title string definition. The

lowest digit of a program number is 1 to 6, depending on the

language. In this example, the typical number is specified as the

program number.

In Japanese, program O7002 of the FANUC standard macros has

the string definition. Set 7000 to parameter No. 9170.

O7002

N9999(‘MANUAL GUIDE’)

M99

2) For parameter No. 9171, specify the program number of the user-

specified macro that has the title string definition. Again, the

typical number is specified as the program number. Suppose that

program O5702 of the user-specified macros has the string

definition. Set 5700 to parameter No. 9171

O5702

N9999(‘Title’)

M99

The MANUAL GUIDE system software checks parameters No.

9170 and No. 9171. When the program number of the new user-

specified macro exists, the software checks whether N9999

exists in program O5702. If it exists, "Title" is displayed.

Otherwise, "MANUAL GUIDE" is displayed in the title display

area.
