B-63423EN/02 USER PROGRAM 14. USER WINDOW PROGRAMS

-95-

14.5 CHARACTER COORDINATE SYSTEM AND GRAPHIC

COORDINATE SYSTEM

The character coordinate system and graphic coordinate system (dot

coordinate system) in user windows are as follows.

1) Character coordinate system

The character coordinate system assumes that X coordinates are

in the horizontal direction and Y coordinates are in the vertical

direction. The X coordinates specify 0 to 79, from left to right.

The Y coordinates specify 0 to 29, from top to bottom.

2) Graphic coordinate system

The graphic coordinate system assumes that X coordinates are in

the horizontal direction and Y coordinates are in the vertical

direction. The X coordinates specify -320 to 319, from left to

right. The Y coordinates specify -232 to 247, from bottom to top.

(0,0)

(0,0)(0,0)

(0,0)

(79,29)

(79,29)(79,29)

(79,29)

247

247247

247

(

((

(0,0

0,00,0

0,0)

))

)

319

319319

319

-320

-320-320

-320

-232

-232-232

-232
