B-63423EN/02 USER PROGRAM 6

. COMMENT OF SOFT-KEYS FOR EACH MENU

-41-

6.12 COMMENT OF SOFT-KEYS IN TEACH MENU

By pushing [TEACH] in the editing menu, the common data input

window is displayed. After data is set, the soft-key menu below is

displayed by pushing the [INPEND] soft-key.

LINE CIRCLE SAVE AUX RAPID CUT

COMMON

RETURN +

LIST WRK-CO OFFSET RETURN +

LINE : Select the linear cutting using a guidance

handwheel.

CIRCLE : Select the circular cutting using a guidance

handwheel.

SAVE : The feed rate and spindle speed are recorded

AUX : After pushing one or continuously several ones of

the auxiliary function switches, the operator can

teach-in these commands.

RAPID : After moving a tool toward a proper position, the

operator can teach-in this tool motion into CNC as

a rapid traverse block.

CUT : Teach-in the tool motion into CNC as a cutting

block.

COMMON : Open the common data input window.

O700n ;

N0130 (“20 01 C010 20”) (Alphanumeric letters for LINE) ;

Maximum 6 ch.

N0131 (“20 01 C018 20”) (Alphanumeric letters for CIRCLE) ;

Maximum 6 ch.

N0138 (“20 01 C030 20”) (Alphanumeric letters for SAVE) ;

Maximum 6 ch.

N0139 (“20 01 C040 20”) (Alphanumeric letters for AUX) ;

Maximum 6 ch.

N0140 (“20 01 C048 20”) (Alphanumeric letters for RAPID) ;

Maximum 6 ch.

N0141 (“20 01 C050 20”) (Alphanumeric letters for CUT) ;

Maximum 6 ch.

N0190 (“20 01 C050 20”) (Alphanumeric letters for CUTCOMMON) ;

Maximum 6 ch.

By pushing [LINE] or [CIRCLE], the figure data input window is

displayed. After data is set, the soft-key menu below is displayed by

pushing the [INPEND] soft-key.

LMT

ON/OFF

SAVE AUX RAPID CUT

COMMON

INPEND
