B-63423EN/02 USER PROGRAM 6

. COMMENT OF SOFT-KEYS FOR EACH MENU

-39-

6.11 COMMENT OF SOFT-KEYS IN CYCLE MOTIONS MENU

By pushing [CYCLE] in Editing menu, the following soft-keys are

displayed.

HOLE PATTER FACE SIDE POCKET RERURN +

LIST WRK-CO OFFSET RETURN +

HOLE : Defining the cycle machining of hole

PATTER : Defining the hole pattern

FACE : Defining the cycle machining of facing

SIDE : Defining the cycle machining of side cutting

POCKET : Defining the cycle machining of pocketing

NOTE

This user program number O730n is specified to

"Macro program number for displaying Comment of

Cycle Motions Menu", which is specified in Start-up

macro program.

O730n ;

N0001 (“20 01 C010 20”) (Alphanumeric letters for HOLE) ;

Maximum 6 ch.

N0002 (“20 01 C018 20”) (Alphanumeric letters for PATTER) ;

Maximum 6 ch.

N0003 (“20 01 C020 20”) (Alphanumeric letters for FACE) ;

Maximum 6 ch.

N0004 (“20 01 C028 20”) (Alphanumeric letters for SIDE) ;

Maximum 6 ch.

N0005 (“20 01 C030 20”) (Alphanumeric letters for POCKET) ;

Maximum 6 ch.
