B-63423EN/02 USER PROGRAM

9. USER PROGRAMS FOR DISPLAYING GUIDANCE DRAWING FIGURE

-63-

9.1 G CODES FOR DRAWING

The following user program is the one, which displays the guidance

drawing figure with the input data item. This user program is called

every time the cursor of the input data item moves.

The guidance drawing figure can be modified by using this user

program. Moreover, the following display tool prepared by macro

executor is used in this user program.

1). G243 : Character string display

2). G202 : Screen hold/erase

3). G240 : Color display setting

4). G244 : Line type setting

5). G242 : Graphic start point setting

6). G01, G02, G03 : Line/Circle draw

7). G206 : Paint display

8). G249 : Graphic cursor display

9). G204 : Rectangle display

NOTE

1. The user program number of displaying the

guidance drawing figure is the number, which is

specified to “Macro program number for displaying

guidance drawing figure” in Start-up macro program.

The program number of the following each menu is

increased by 1.

1-1. Macro program number for displaying guidance

drawing figure of G code menu = 8602

(1). Initial Setting = O8602

(2). Tool Definition = O8603

(3). MSF code = O8604

(4). Comp. = O8605

(5). Positioning = O8606
