9. USER PROGRAMS FOR DISPLAYING GUIDANCE DRAWING FIGURE

USER PROGRAM B-63423EN/02

-68-

O****

if[guide_frequency eq second_time]then

if[cursor eq 3 ]then

call fig_clear Clear the guidance drawing figure at prompts 1 and 2.

call **** Create the guidance drawing figure at prompt 3.

else

if[previous_cursor eq 3 ]then

call fig_clear

endif

call **** Create the guidance drawing figure at prompts 1 and 2.

endif

previous_cursor = cursor Hold the cursor at the current position.

endif

m99

3) The blinking cursor in a guidance drawing figure is called the

second cursor. There are many different methods to control the

second cursor. With the FANUC standard macros, for example,

the ordinal number on the process data is specified for #1 in

FIG*.SRC. Then, program O6008 is called. Within program

O6008, when the current cursor position matches the ordinal

number on the process data, the address blinks. Otherwise, the

normal display is provided.

#1=2

call fig_cursor

G243X50Y3(I)

call fig_clear and call fig_cursor shown in the above examples are

contained in FIGCOM.SRC, which is the source having a set of

routines common to guidance drawing figure macros. The following

are main common routines:

Routine name Description

fig_clear Clears the guidance drawing figure area.

fig_line Draws a line with an arrow.

fig_cw Draws a circle with an arrow (CW).

fig_ccw Draws a circle with an arrow (CCW).

fig_mark Draws a cross.

fig_cursor Enables or disables the blinking of the second cursor.

fig_character Draws a box around characters.

fig_language Changes the language in a guidance drawing figure.

4) A macro program for guidance drawing figures is started each

time the cursor moves. To change process attributes depending

on input data, therefore, the corresponding attributes must be

changed within this macro program. For example, to display

items for rough machining, and to hide them for finish

machining, change the attributes within the program accordingly.

Create the

figure only

upon the

second

startup of

the

program.

Clear guidance drawing figure 3 when the cursor was

previously positioned at prompt 3.

:6008 if[cursor eq #1]then

cursor_on

else

cursor_off

endif

m99

1: Ordinal number on the

process data

cursor_on:G240P-7C14L1

(Cursor blinking)

cursor_off:G240P7C14L0
