B-63423EN/02 USER PROGRAM 13. PMC CUSTOMIZING TOOLS

-87-

13.9 MANUAL PULSE BOX CONTROL SIGNALS

The following signals (DI) are provided so that the teaching functions

[AUX], [RAPID], and [CUT] can also be started from the manual

pulse box:

PM PMC signal Description

R988.0(CUTT) Teaching for cutting

R988.1(RPDT) Teaching for rapid traverse

R988.2(AUXT) Teaching for auxiliary functions

When one of the above DI signals is set to 1 by pushing the

corresponding button on the manual pulse box, the MANUAL

GUIDE system software sets the following signal (DO) to 1, to notify

the PMC that it received the DI signal:

R959.1(RSOF) = 1 : Reception of the user program calling signal by

the MANUAL GUIDE

The PMC program must hold the user program calling signal to 1

until the RSOF signal is set to 1. When the use program calling signal

is reset to 0, the RSOF signal is also reset to 0.
