B-63423EN/02 USER PROGRAM 6

. COMMENT OF SOFT-KEYS FOR EACH MENU

-33-

PATH PLANE EXEC ROTATE SECT.P 3-PLAN PARAM RETURN

PATH : Switch to the tool path drawing screen.

EXEC : Start drawing after drawing a blank

ROTATE : Rotate a generated drawing.

PLANE : Display a plan view of a work-piece.

SECT.P : Display a cross-sectional view of a work-piece.

3-PLAN : Display a tri-plane view from a drawn machining

profile.

PARAM : Change the drawing parameters.

O700n ;

N0043 (“20 01 C010 20”) (Alphanumeric letters for PATH) ;

Maximum 6 ch.

N0046 (“20 01 C028 20”) (Alphanumeric letters for PLANE) ;

Maximum 6 ch.

N0044 (“20 01 C030 20”) (Alphanumeric letters for EXEC) ;

Maximum 6 ch.

N0045 (“20 01 C038 20”) (Alphanumeric letters for ROTATE) ;

Maximum 6 ch.

N0047 (“20 01 C040 20”) (Alphanumeric letters for SECT.P) ;

Maximum 6 ch.

N0048 (“20 01 C048 20”) (Alphanumeric letters for 3-PLAN) ;

Maximum 6 ch.

N0049 (“20 01 C050 20”) (Alphanumeric letters for PARAM) ;

Maximum 6 ch.
