B-63423EN/02 USER PROGRAM 7. COMMENT OF INPUT DATA ITEM

-49-

7.2

COMMENT OF INPUT DATA ITEM IN CONTOUR PROFILE

By pushing [CONTUR] of G-code menu, the following soft-keys of

Contour profile menu are displayed.

By pushing each soft-keys, the pop-up window of the menu will be

displayed. This time, it is explained as an example of START POINT

menu. By pushing [START POINT], the following Input Data

Window will be displayed.

The each data item in the window can be modified by using the

following user macro program.

NOTE

1 The user program number (O711n) of this menu is

the number, which is added 10 to the number of

“Macro program number for displaying Comment of

Contour Profile menu” in Start-up macro program.

The program number of the following each menu is

increased by 10.

(1). START POINT menu = O711n

(2). LINE menu = O712n

(3). CW ARC menu = O713n

(4). CCW ARC menu = O714n

(5). CHAMFER menu = O715n

(6). ROUND menu = O716n

(7). END menu = O717n

(8). TRANS COPY menu = O718n

(9). ROTATE COPY menu = O719n

(10). MIRROR COPY menu = O720n

RETURN

RECALC.

TANGNT

ENDROUND

CHAMF

ARC

CCW

ARC

LINE

START

POINT

START POINT X X=

START POINT Y Y=

START POINT TYPE E= START POINT

START POSITIO

Title (1)

The 1st - m’th item
