1. LIST OF USER PROGRAMS SAMPLE PROGRAM B-63423EN/02

-118-

Large

Classification

Small

Classification

Menu Comment Attribute Figure Checking

Menu Soft-keys O760n ---- ---- ----

Square Surface O761n O8461 O8661 O8861

Facing

Circle Surface O762n O8462 O8662 O8862

Menu Soft-keys O770n ---- ---- ----

Square Side O771n O8471 O8671 O8871

Circle Side O772n O8472 O8672 O8872

Track Side O773n O8473 O8673 O8873

One Side O774n O8474 O8674 O8874

Side Cutting

Contour Side O775n O8475 O8675 O8875

Menu Soft-keys O780n ---- ---- ----

Square Pocket O781n O8481 O8681 O8881

Circle Pocket O782n O8482 O8682 O8882

Track Pocket O783n O8483 O8683 O8883

Grooving O784n O8484 O8684 O8884

Contour Pocket O785n O8485 O8685 O8885

Cycle Motion

Pocketing

Contour Grooving O786n O8486 O8686 O8886

l When the measurement cycle option is provided, the following programs

are added:

Large

Classification

Small

Classification

Menu Comment Attribute Figure Checking

Menu Soft-keys O620n ---- ---- ----

Measurement of Probe Length O621n O6511 O6551 O6611

Measurement of Diameter O622n O6512 O6552 O6612

Measurement (A) of Offset O623n O6513 O6553 O6613

Calibration

Cycles

Measurement (B) of Offset O624n O6514 O6554 O6614

Menu Soft-keys O630n ---- ---- ----

Measurement of X/Y/Z Single

Surface

O631n O6521 O6561 O6621

Measurement of Web Width O632n O6522 O6562 O6622

Measurement of Groove Width O633n O6523 O6563 O6623

Measurement of Outside Circle O634n O6524 O6564 O6624

Measurement of Inside Circle O635n O6525 O6565 O6625

Measurement of Outside

Rectangular

O636n O6526 O6566 O6626

Measurement of Inside

Rectangular

O637n O6527 O6567 O6627

Measurement of Outside Corner O638n O6528 O6568 O6628

Measurement of Inside Corner O639n O6529 O6569 O6629

Measurement of Bolt-Hole Circle O640n O6530 O6570 O6630

Measurement of 4 Holes Center O641n O6531 O6571 O6631

Measurement of Workpiece

Angle

O642n O6532 O6572 O6632

Cycle Motion

Measuring

Cycles

Measurement of 2 Holes Angle O643n O6533 O6573 O6633
