MANUAL GUIDE (for Milling) Programming manual Page 78

Programming manual

Page of 603

/ 603

10. USER PROGRAMS FOR CHECKING INPUTTED DATA

USER PROGRAM B-63423EN/02

-70-

NOTE

2 Macro program number for checking inputted data

of Contour menu = 8811

(1). Start Point = O8611

(2). Line = O8612

(3). Circle CW = O8613

(4). Circle CCW = O8614

(5). Chamfering = O8615

(6). Corner R = O8616

(7). End = O8617

(8). Linear Movement = O8618

(9). Rotation = O8619

(10). Mirror Transformation = O8620

3 Macro program number for checking inputted data

of Hole machining menu = 8832

(1). Drilling = O8832

(2). Boring = O8833

(3). Tapping = O8834

(4). Rigid tapping = O8834

4 Macro program number for checking inputted data

of Hole pattern menu = 8841

(1). Points = O8841

(2). Line = O8842

(3). Grid = O8843

(4). Square = O8844

(5). Circle = O8845

(6). Arc = O8846

5 Macro program number for checking inputted data

of Facing menu = 8861

(1). Square Surface = O8861

(2). Circle Surface = O8862

6 Macro program number for checking inputted data

of Side cutting menu = 8871

(1). Square Side = O8871

(2). Circle Side = O8872

(3). Track Side = O8873

(4). One Side = O8874

(5). Contour = O8875

7 Macro program number for checking inputted data

of Pocketing menu = 8881

(1). Square Pocket = O8881

(2). Circle Pocket = O8882

(3). Track Pocket = O8883

(4). Groove = O8884

(5). Contour Pocket = O8885

(6). Contour Groove = O8886
