B-63423EN/02 USER PROGRAM 16. MEASUREMENT CYCLE

-111-

16.4 MACRO PROGRAMS FOR DISPLAYING GUIDANCE

DRAWING FIGURES

The macro programs for displaying guidance drawing figures are the

same as those for normal cycle machining.

NOTE

1 The number of the user program for displaying

guidance drawing figures suitable for data items is

set for the guidance drawing figure macro number,

in the startup macro program. The numbers of the

subsequent menus are incremented by 1.

1-1Number of the guidance drawing figure macro for

the calibration menu = 6551

(1) Probe = O6551

(2) Diameter = O6552

(3) Offset A = O6553

(4) Offset B = O6554

1-2Number of the guidance drawing figure macro for

the measurement cycle menu = 6561

(1) X/Y/Z Single Surface menu = O6561

(2) Web Width menu = O6562

(3) Groove Width menu = O6563

(4) Outside Circle menu = O6564

(5) Inside Circle menu = O6565

(6) Outside Rectangular menu = O6566

(7) Inside Rectangular menu = O6567

(8) Outside Corner menu = O6568

(9) Inside Corner menu = O6569

(10) Bolt-Hole-Circle menu = O6570

(11) 4 Holes Center menu = O6571

(12) Workpiece Angle menu = O6572

(13) 2 Holes Angle menu = O6573
