B-63423EN/02 USER PROGRAM 13. PMC CUSTOMIZING TOOLS

-85-

• Set 0 to R961 when line/circle cutting are not necessary.

• R979 (information of setting change) is a signal to inform

CNC that the data for line/circle cutting were changed.

Sequence i) Set data for R961 - R974

ii) Set "0" to R979 after setting the above data

iii) CNC begins to read data

iv) CNC set "1" to R979 after reading

• If some of data were changed during executing a cutting by

guidance handwheel , all the data must be set again.

NOTE

The all procedure for the above data signals are

already prepared as the standard custom macro

program. So, MTB needs not to make them by

themselves, if they need not to modify them.

2) Synchronous feed with a guidance handwheel

G023.4 (HDLF)

When the above signal is "1", machine motions are controlled as

follows.

During automatic operation of machining program, the feedrate of

line (G01) or circle (G02/G03) motions is not controlled by

inputted feedrate in a program, but a guidance handwheel rotation.

The tangential speed of motion is controlled by synchronizing

with a guidance handwheel rotation.

NOTE

During running in dry run mode or machining

simulation, The above synchronous feed function

cannot be used. So, when the signal "DRN" is "1",

set the above signal "HDLF" to "0" always.
