B-63423EN/02 USER PROGRAM 7. COMMENT OF INPUT DATA ITEM

-51-

Example )

The definition of Input data item in START POINT menu

O7112 ;

N9999 (‘START POINT’) ;

N9998 (‘STRAT POINT (DETAIL SET)’) ;

N0001 (‘START POINT X’) ;

N0002 (‘START POINT Y’) ;

N0003 (‘START POINT TYPE’) ;

N0004 (‘ISLAND Z CO-ORD.’) ;

N0005 (‘GROOVE Z CO-ORD.’) ;

N0006 (‘MOV TYPE TO ST.PT.’) ;

N0007 (‘FEED RATE TO ST.PT.’) ;

N0008 (‘FEED RATE FROM ST.PT.’) ;

N0009 (‘COMP. DIRECTION ’) ;

N0300 (‘1’) ;

N0301 (“20 01 C010 20”)(‘START‘) ;

N0302 (“20 01 C010 20”)(‘ISLAND‘) ;

N0303 (“20 01 C010 20”)(‘NXT MV‘) ;

N0304 (“20 01 C028 20”)(‘ DIRECT ‘) ;

N0351 (‘1’) ;

N0352 (‘2’) ;

N0353 (‘3’) ;

N0354 (‘4’) ;

N0600 (‘1’) ;

N0601 (“20 01 C010 20”)(‘ RAPID ‘) ;

N0602 (“20 01 C018 20”)(‘ CUT ‘) ;

N0651 (‘1’) ;

N0652 (‘2’) ;

N0900('5');

N0901("20 01 C028 20")(' LEFT ');

N0902("20 01 C030 20")(' RIGHT ');

N0903("20 01 C040 20")('NO OUT');

N0951('1');

N0952('2');

N0953('3');

M99 ;
