6. COMMENT OF SOFT-KEYS FOR EACH MENU

USER PROGRAM B-63423EN/02

-34-

6.7 COMMENT OF SOFT-KEYS IN LIST MENU

By pushing [LIST] in the large-classified menu, the list menu below is

displayed. In this menu, selection, copying, and other program

operations can be performed.

SELECT COPY DELETE CNV NC O

RETURN

SELECT : Select a program.

COPY : Copy a program.

DELETE : Delete a program.

CNV NC : Convert a conversational statement into an NC

statement.

O SEARCH : Search for a program.

O700n ;

N0007 (“20 01 C010 20”) (Alphanumeric letters for SELECT) ;

Maximum 6 ch.

N0008 (“20 01 C020 20”) (Alphanumeric letters forCOPY) ;

Maximum 6 ch.

N0009 (“20 01 C028 20”) (Alphanumeric letters forDELETE) ;

Maximum 6 ch.

N0187 (“20 01 C030 20”) (Alphanumeric letters for CNV NC) ;

Maximum 6 ch.

N0183 (Alphanumeric letters for O SEARCH) ;

Maximum 6 ch.
