MANUAL GUIDE (for Milling) Programming manual Page 68

Programming manual
8. DATA STRUCTURE OF MACHINING PROGRAM
USER PROGRAM B-63423EN/02
-60-
8.2 DETAIL OF DATA ATTRIBUTE
1). Machining Kind
The number of G code is specified. For a example, Initial Setting
menu is G300, and it is set to 300. Moreover, it is set to –1, except
for G code like the MSF code menu. In the case of Line menu, it
is set to –1, because it is not able to decide whether it is G00 or
G01.
2). Address
The address of the argument for G code is specified as follows.
Address Setting Address Setting
A1N14
B2P16
C3Q17
D4R18
E5S19
F6T20
G *U21
H8V22
I9W23
J10X24
K11Y25
L12Z26
M13END0
When the address is set to 0, it is recognized the end of the data
attribute.
As to the address G, in order to use the address of G code, the
following group number of G code is set the address.
Group Setting Group Setting Group Setting
00 30 09 39 18 48
01 31 10 40 19 49
02 32 11 41 20 50
03 33 12 42 21 51
04 34 13 43 22 52
05 35 14 44 23 53
06 36 15 45 24 54
07 37 16 46 25 55
08 38 17 47
