M-code direct output function

(High Response Function)

11/16

SHEET

Note

• When a direct signal is turned on and also off within a program, the M-

code group number (n: given by address P) of each command has to be

the same value. When a turning-on-command and a turning-off-

command are given in different programs respectively, each M-code

group number has to be specified different values.

Ex) When a direct signal is turned on in a program and turned off in

another program like the following example program, each M-code

group number (n) has to be set different value.

• When several blocks with M-code for direct signal output are specified

consecutively between blocks without this command such as a motion

command, empty block (only “;”) or so on, a command type of M-code for

direct signal output has to be the same. If different command type is

specified, compile error 1028 will be generated.

O8000

G90G01X10000F1000;

M40P1Q3; (Turn on a signal after pulse distribution of X axis is finished.)

O8001

G90G01Y10000F1000;

M40P2Q2; (Turn off a signal after pulse distribution of X axis is finished.)

Ex) The following program generates compile error 1028.

O8000;

G90G01X0F1000;

M40P1Q3; (“Output after pulse distribution end” type)

M41P1Q1; (“immediate output” type)

G90G01X10000F1000;

---------

Ex) The following program generates no compile error.

O8000;

G90G01X0F1000;

M40P1Q1; (“immediate output ” type)

M41P1Q1; (“immediate output” type)

G90G01X10000F1000;

---------
