POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 178

Connection manual (Function)

Page of 1173

/ 1173

B–63173EN–1/01

4. REFERENCE POSITION ESTABLISHMENT

165

[Classification] Output signal

[Function] These signals report that the tool is at the refernce position on a controlled

axis.

These siganls are provided for axes in a one–to–one corespondence.

A number appended to a signal represents a controlled axis number.

1 : Reference position return end signal for the first axis

2 : Reference position return end signal for the second axis

3 : Reference position return end signal for the third axis

ZP 1

[Output condition] These signals turn to “1” when:

D Manual reference position returns is completed, and the current

position is in the in–position area.

D Automatic reference position return (G28) is completed, and the

current position is in the in–position area.

D Reference position return check (G27) is completed, and the current

position is in the in–position area.

These signals turn to “0”when:

D The tool has moved from the reference position.

D An emergency stop is applied.

D A servo alarm is raised.

[Classification] Output signal

[Function] Notify the system that the reference position has been established.

A reference position establishment signal is provided for each axis. The

number appended to each signal name indicates the number of the

controlled axis.

1 : 1st–axis reference position establishment signal

2 : 2nd–axis reference position establishment signal

3 : 3rd–axis reference position establishment signal

ZRF 1

[Output condition] The signals are set to 1 in the following case:

⋅ When the reference position is established after manual reference

position return

⋅ When the reference position is established using the absolute–position

detector at initial power–on

Reference position

return end signals ZP1 to

ZP8 <F094>

Reference position

establishment signal

ZRF1 to ZRF8<F120>
