POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 32

Connection manual (Function)

Page of 1173

/ 1173

B–63173EN–1/01

1. AXIS CONTROL

When position control is disabled for the controlled axes (when the servo

is off, during emergency stop, or during a servo alarm), if the machine is

moved, a positional error occurs. Follow–up is a function for changing

the current position of the CNC and reset the error counter to zero,

assuming a command corresponding to the error has been specified.

You can select whether to perform follow–up for axes for which the servo

is turned off.

Follow–up is always performed during emergency stop or a servo alarm.

When signal *FLWU is 1, follow–up is not performed. The error is added

to the error counter as a servo error. In this case, the machine moves to

compensate for the error when the servo off signal changes to 0.

In general, follow–up is not used if the machine is mechanically clamped

when position control is disabled for the controlled axes.

When *FLWU is “0”, the follow-up function is engaged. The present

position of the CNC is changed to reset the error counter to zero. The

machine tool remains in a deviated position, but since the present position

of the CNC changes correspondingly, the machine moves to the correct

position when the absolute command is next applied.

In general, follow–up should be used when motors are driven by

mechanical handles.

[Classification] Input signal

[Function] Select whether to perform follow–up when the servo is turned off.

[Operation] 0: Performs follow–up.

1: Does not perform follow–up.

#7 #6 #5 #4 #3 #2 #1 #0

G007 *FLWU

CONNECTION MANUAL

(This manual)

1.2.8 Servo Off (Mechanical handle)

1.2.7

Follow–up

General

D When follow–up is not

performed for the axes

for which the servo is

turned off

D When follow–up is

performed for the axes

for which the servo is

turned off

Signal

Follow–up signal

*FLWU <G007#5>

Signal address

Reference item
