11. PROGRAM COMMAND

B–63173EN–1/01

420

NOTE

Setting value 0 is invalid. No custom macro can be called

by G00.

6071 M code that calls the subprogram of program number 9001

6072 M code that calls the subprogram of program number 9002

6073 M code that calls the subprogram of program number 9003

6074 M code that calls the subprogram of program number 9004

6075 M code that calls the subprogram of program number 9005

6076 M code that calls the subprogram of program number 9006

6077 M code that calls the subprogram of program number 9007

6078 M code that calls the subprogram of program number 9008

6079 M code that calls the subprogram of program number 9009

[Data type] Two–word

[Valid data range] 1 to 99999999

These parameters set the M codes that call the subprograms of program

numbers 9001 through 9009.

NOTE

Setting value 0 is invalid. No custom macro can be called

by M00.

6080 M code that calls the custom macro of program number 9020

6081 M code that calls the custom macro of program number 9021

6082 M code that calls the custom macro of program number 9022

6083 M code that calls the custom macro of program number 9023

6084 M code that calls the custom macro of program number 9024

6085 M code that calls the custom macro of program number 9025

6086 M code that calls the custom macro of program number 9026

6087 M code that calls the custom macro of program number 9027

6088 M code that calls the custom macro of program number 9028

[Data type] Two–word

D Setting M codes that call

subprograms of program

Nos.9001 to 9009

D Setting M codes that call

custom macros of

no.9020 to 9029
