B–63173EN–1/01

9. SPINDLE SPEED FUNCTION

342

SGB: Gear switching method

0 : Method A (Parameters No. 3741 to 3743 for the maximum spindle

speed at each gear are used for gear selection.)

1 : Method B (Parameters No. 3751 and 3752 for the spindle speed at the

gear switching point are used for gear selection.)

SGT: Gear switching method during tapping cycle (G84 and G74)

0 : Method A (Same as the normal gear switching method)

1 : Method B (Gears are switched during tapping cycle according to the

spindle speed set in parameters No. 3761 and 3762).

NSF: When an S code command is issued in constant surface speed control,

0 : SF is output.

1 : SF is not output.

SFA: The SF signal is output:

0 : When gears are switched

1 : Irrespective of whether gears are switched

#7 #6 #5 #4 #3 #2 #1 #0

TCW3706 CWM ORM GTT PG2 PG1

[Data type] Bit

PG2, PG1 Gear ratio of spindle to position coder

Spindle speed

Number of position coder revolutions

Magnification PG2 PG1

1 0 0

2 0 1

Magnification=

4 1 0

8 1 1

GTT Selection of a spindle gear selection method

0 : Type M

1 : Type T
