B–63173EN–1/01

9. SPINDLE SPEED FUNCTION

390

5241

Maximum spindle speed in rigid tapping (first–stage gear)

5242

Maximum spindle speed in rigid tapping (second–stage gear)

5243

Maximum spindle speed in rigid tapping (third–stage gear)

[Data type] Two–word

[Unit of data] rpm

[Valid data range] Spindle and position coder gear ratio

1 : 1 0 to 7400

1 : 2 0 to 9999

1 : 4 0 to 9999

1 : 8 0 to 9999

These parameters set the maximum spindle speed for every gear in rigid

tapping.

NOTE

In a system having one–stage gear, set the same value as

parameter No. 5241 to parameter No. 5243. In a system

having two–stage gear, set the same value as parameter

No. 5242 to parameter No. 5243. If it is not set as such, P/S

alarm no. 200 will be informed.

5261

Linear acceleration/deceleration time constant for the spindle and tapping axis

(first–stage gear)

5262

Linear acceleration/deceleration time constant for the spindle and tapping axis

(second–stage gear)

5263

Linear acceleration/deceleration time constant for the spindle and tapping axis

(third–stage gear)

[Data type] Word

[Unit of data] ms

[Valid data range] 0 to 4000

These parameters set the spindle and tapping axis’s time constant for

every gear during linear acceleration/deceleration in rigid tapping.

Set the time required until a spindle speed reaches the maximum spindle

speed (parameter Nos. 5241 and greater). The actual time constant is a

proportional value between the maximum spindle speed and the specified

spindle speed.
