6. INTERPOLATION FUNCTION

B–63173EN–1/01

238

The G00 command moves a tool to the position in the workpiece system

specified with an absolute or an incremental command at a rapid traverse

rate.

In the absolute command, coordinate value of the end point is

programmed.

In the incremental command the distance the tool moves is programmed.

The tool path is determined by selecting one of the following with

parameter LRP (No. 1401#1):

D Linear interpolation type positioning

The tool path for positioning is determined in the same manner as

linear interpolation (G01). The tool moves at an appropriate speed so

that positioning can be performed in the shortest time without the

speed exceeding the rapid traverse rate for each axis.

D Non–linear interpolation type positioning

Positioning is performed with each axis independently at the rapid

traverse rate. Generally, the tool path is not a straight line.

The rapid traverse rate in the G00 command is set to the parameter

No.1420 for each axis independently by the machine tool builder. In the

positioning mode actuated by G00, the tool is accelerated to a

predetermined speed at the start of a block and is decelerated at the end

of a block. Execution proceeds to the next block after confirming the

in–position.

1401

#6 #5 #4 #3 #2 #1

LRP

[Data type] Bit

LRP Positioning (G00)

0 : Positioning is performed with non–linear type positioning so that the

tool moves along each axis independently at rapid traverse.

1 : Positioning is performed with linear interpolation so that the tool

moves in a straight line.

1420 Rapid traverse rate for each axis

[Data type] Two–word axis

Increment system

Unit of data

Valid data range

Increment s

stem

Unit of data

IS-A, IS-B IS-C

Millimeter machine 1 mm/min 30 – 240000 30 – 100000

Inch machine 0.1 inch/min 30 – 96000 30 – 48000

Rotaion axis 1 deg/min 30 – 240000 30 – 100000

Set the rapid traverse rate when the rapid traverse override is 100% for

each axis.

6.1

POSITIONING

General

Parameter

[Unit of data]

[Valid data range]
