B–63173EN–1/01

4. REFERENCE POSITION ESTABLISHMENT

177

[Classification] Output signal

[Function] Notify the system that the reference position has been established.

A reference position establishment signal is provided for each axis. The

number appended to each signal name indicates the number of the

controlled axis.

1 : 1st–axis reference position establishment signal

2 : 2nd–axis reference position establishment signal

3 : 3rd–axis reference position establishment signal

ZRF 1

[Output condition] The signals are set to 1 in the following case:

⋅ When the reference position is established after manual reference

position return

⋅ When the reference position is established using the absolute–position

detector at initial power–on

The signals are set to 0 in the following case:

⋅ When the reference position is lost

ZRNG043

#6 #5 #4 #3 #2 #1 #0

+J8G100

+J7

+J6

+J5

+J4

+J3

+J2

+J1

-J8G102

-J7

-J6

-J5

-J4

-J3

-J2

-J1

ZR8G210

ZR7

ZR6

ZR5

ZR4

ZR3

ZR2

ZR1

MZRNF004

#6 #5 #4 #3 #2 #1 #0

ZP8F094

ZP7

ZP6

ZP5

ZP4

ZP3

ZP2

ZP1

ZRF8F120

ZRF7

ZRF6

ZRF5

ZRF4

ZRF3

ZRF2

ZRF1

Reference position

establishment signal

ZRF1 to ZRF8<F120>

Signal address
