5. Alarm and message

The details of the alarm No.5800 are displayed in the diagnostic data No.50 and

No.60.

Number. Message Content

5800 System combination

mismatch

The function to be executed is not effective

because the combination of the system is

incorrect. Please refer to the diagnostic screen

for details.

Diagnostic data No.50: the incorrect software is

displayed.

Diagnostic data No.60: the function not to be

used is displayed.

The details of the alarm No.5800

The software to cause the alarm No.5800 is displayed.

PMC : PMC control software is incorrect.

SVO : Digital servo control software is incorrect

SYS : CNC control software is incorrect.

The function to cause the alarm No.5800 is displayed.

HPS : High-speed position switch can not be used.

Page

24 / 26

Date Sign

Contents

FANUC Power Mate i-MODEL D/H

High Speed Position Switch

specifications

B-63173EN-1/01-31

TITLE

DRAWING

Note

•

When the alarm No.5800 occurs, the system enters into the emergency

stop state and any axes cannot be moved.

When the high-speed position switch signal is not used, set the value out

of range (for instance No.8516=0 or so on.) to the parameter No.8516 and

No.8517, and the power is turned off and on. Then the alarm No.5800 can

be avoided.

#7 #6 #5 #4 #3 #2 #1 #0

Diagnostic data 50 SYS SVO PMC

#7 #6 #5 #4 #3 #2 #1 #0

Diagnostic data 60 HPS
