12. DISPLAY/SET/EDIT

447

6711 Number of machined parts

Setting entry is acceptable.

[Data type] Two–word

[Unit of data] One piece

[Valid data range] 0 to 99999999

The number of machined parts is counted (+1) together with the total

number of machined parts when the M02, M30, or a M code specified by

parameter No. 6710 is executed.

NOTE

When bit 0 (PCM) of parameter No. 6700 is set to 1, the

number of parts is not counted with M02 and M30.

6712 Total number of machined parts

Setting entry is acceptable.

[Data type] Two–word

[Unit of data] One piece

[Valid data range] 0 to 99999999

This parameter sets the total number of machined parts.

The total number of machined parts is counted (+1) when M02, M30, or

an M code specified by parameter No. 6710 is executed.

NOTE

When bit 0 (PCM) of parameter No. 6700 is set to 1, the

number of parts is not counted with M02 and M30.

6713 Number of required parts

Setting entry is acceptable.

[Data type] Word

[Unit of data] One piece

[Valid data range] 0 to 9999

This parameter sets the number of required machined parts.

Required parts finish signal PRTSF is output to PMC when the number

of machined parts reaches the number of required parts. The number of

parts is regarded as infinity when the number of required parts is zero. The

PRTSF signal is then not output.
