POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 970

Connection manual (Function)

Page of 1173

/ 1173

FANUC LTD

13/18

EDIT

DATE

DESIG.

DESCRIPTION

CUST.

SHEET

TITLE

DRAW.NO.

FANUC Power Mate i-MODEL H

CONNECTION MANUAL (FUNCTION)

High Speed Skip function

B-63173EN-1/01-26

--------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------

SignalSignal

High-Speed SkipHigh-Speed Skip SignalSignal

DI3DI300 ∼∼ DI37DI37

< X1003#0< X1003#0∼∼#7 >#7 >

[Classification][Classification] Input signal

[Function][Function] These signals interrupt skip cutting. That is, the position, where

a skip signal turns to "1" in a command program block containing

G31, G31P1 to P8 R_, is stored in a custom macro variable, and

the move command of the block is interrupted after moving the

specified traveling distance from skip signal. In this case, until

all other commands (such as miscellaneous functions) of the

block are completed, machining never proceeds to the next block.

Which of the eight skip signals is applicable to blocks containing

the G codes can be determined by parameter (No. 6202 to 6205,

No 6270 to 6273). The eight skip signals can correspond to the G

codes on a one-to-one basis. One skip signal can also be made

applicable to multiple G codes. Conversely, multiple skip signals

can be made applicable to one G code.

[Operation][Operation] When a skip signal turns to “1”, the control unit functions as

described below.

When a block contains a G code for skip cutting (from G31,

G31P1 to P8), and the skip signal is made applicable to the

command by parameter setting, the control unit reads and

stores the current position of the specified axis at that time.

The control unit stops the axis after moving the specified

traveling distance from skip signal and then cancels the

remaining distance that the block was supposed to be moved.

Signal addressSignal address

#7 #6 #5 #4 #3 #2 #1 #0

X1003 DI37 DI36 DI35 DI34 DI33 DI32 DI31 DI30

Contents Summary of POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function)

Page 1GE Fanuc Automation Computer Numerical Control Products Power Mate i-D/H Connection Manual (Function) B- 63173EN-1/01 June 1997
Page 2Warnings and notices for GFLE-003 this publication Warning In this manual we have tried as much as possible to describe all the various matters. However, we cannot describe all the matters which must not be done, or which cannot be done, because there are so many possibilities. Therefore, matters wh
Page 3B–63173EN–1/01 DEFINITION OF WARNING, CAUTION, AND NOTE DEFINITION OF WARNING, CAUTION, AND NOTE This manual includes safety precautions for protecting the user and preventing damage to the machine. Precautions are classified into Warning and Caution according to their bearing on safety. Also, suppl
Page 4B–63173EN–1/01 PREFACE This manual describes all the NC functions required to enable machine tool builders to design their CNC machine tools. The following items are explained for each function. 1. General Describes feature of the function. Refer to Operator’s manual as requied. 2. Signals D
Page 5PREFACE B–63173EN–1/01 Signal description Relation of interface signals among the CNC, the PMC and the machine tool is shown below: [For Power Mate i–D (one–path control) and Power Mate i–H] G000– X000– CNC PMC Machine F000– Y000– tool [For Power Mate i–D (two–path control)] CNC G000– X000– Path 1 F
Page 6B–63173EN–1/01 PREFACE D Expression of signals One address accommodates eight signals. Address Symbol (#0 to #7 indicates bit position) #7 #6 #5 #4 #3 #2 #1 #0 F000 OP SA STL SPL RWD Parameter description Parameters are classified by data type as follows : Dta type Valid data range Remarks Bit 0 or
Page 7PREFACE B–63173EN–1/01 D Notation of bit type and bit axis type parameters Data No. Data (#0 to #7 indicates bit position) #7 #6 #5 #4 #3 #2 #1 #0 0000 SEQ INI ISO TVC D Notation of parameters other than bit type and bit axis type Data No. Data 1023 Servo axis number of a specific axis NOTE In an it
Page 8B–63173EN–1/01 PREFACE Related Manuals The table below lists manuals related to MODEL D and MODEL H of Power Mate i. In the table, this manual is marked with an asterisk(*). Table 1 Related manuals Specification Manual name Number DESCRIPTIONS B–63172EN CONNECTION MANUAL (HARDWARE) B–63173EN CONNECT
