・Sub-program call

Sub-program can be called by specifying M98 and a sub-program number P.

Optional block skip function can be applied to the block with M98 (sub-program

call).

Example)

1. In case a sub-program is called:

M98 Ppppp ;

Sub-program number

Repeating number can not be specified.

Use “WHILE” statement to call a sub-program repeatedly.

In case of program number 8 digits, calling format is the same.

2.In case optional block skip function is used:

/1 M98 P7000;

When optional block skip signals BDT1 is set to 1 before

the CNC start reading a block containing /1, the block is ignored.

・Sub-program call nesting

A sub-program can call another sub-program. Sub-program call can be

nested to a depth of four levels including sub-program call from

main-program.

Main-program Sub-program Sub-program Sub-program Sub-program

(1 level nesting) (2 level nesting) (3 level nesting) (4 level nesting)

O8001;

M98P7000;

O7000;

M98P7001;

M99;

O7001;

M98P7002;

M99;

O7002;

M98P7003;

M99;

O7003;

M99;

Note

1. A sub-program can not start alone directly. A sub-program must

be called from a main-program (O8000 to O8031).

2. A sub-program can not call a main-program. (If call, an alarm

1020 occurs.) It is only a sub-program that a program can call.

EDIT

DATE DISIGNE

DESCRIPTION

TITLE

DRAW

FANUC Power Mate i - MODEL H

Sub program call for high-speed

response function

B-63173EN-1/01-39

SHEET

3/12

APPROV.

FANUC LTD

01 020621 New design
