POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 45

Connection manual (Function)

Page of 1173

/ 1173

B–63173EN–1/01

1. AXIS CONTROL

3622

Number of the pitch error compensation position at extremely positive position

for each axis

NOTE

After setting this parameter, turn the power off then on again

so that the setting will take effect.

[Data type] Word axis

[Unit of data] Number

[Valid data range] 0 to 1023

Set the number of the pitch error compensation position at the extremely

positive position for each axis.

NOTE

This value must be larger than set value of parameter (No.

3620).

3623

Magnification for pitch error compensation for each axis

NOTE

After setting this parameter, turn the power off then on again

so that the setting will take effect.

[Data type] Byte axis

[Unit of data] 1

[Valid data range] 0 to 100

Set the magnification for pitch error compensation for each axis.

If the magnification is set to 1, the same unit as the detection unit is used

for the compensation data.

3624

Interval between pitch error compensation positions for each axis

NOTE

After setting this parameter, turn the power off then on again

so that the setting will take effect.

[Data type] Two–word axis
