POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 1046

Connection manual (Function)

Page of 1173

/ 1173

No.

8520 Axis number correspond to the first high speed position switch

8521 Axis number correspond to the second high speed position switch

8522 Axis number correspond to the third high speed position switch

8523 Axis number correspond to the fourth high speed position switch

8524 Axis number correspond to the fifth high speed position switch

8525 Axis number correspond to the sixth high speed position switch

8526 Axis number correspond to the seventh high speed position switch

8527 Axis number correspond to the eighth high speed position switch

8528 Axis number correspond to the ninth high speed position switch

8529 Axis number correspond to the tenth high speed position switch

8530 Axis number correspond to the eleventh high speed position switch

8531 Axis number correspond to the twelfth high speed position switch

8532 Axis number correspond to the thirteenth high speed position switch

8533 Axis number correspond to the fourteenth high speed position switch

8534 Axis number correspond to the fifteenth high speed position switch

8535 Axis number correspond to the sixteenth high speed position switch

(Data type) Byte

(Valid data range): 0,1,2,3,..., controlled axis number

The controlled axis number corresponding to each high-speed position

switch is specified. If 0 is set, that high-speed position switch is not

effective.

Note)

In case of Power Mate i-D dual path control, this parameter must be set to 1

in both paths.

Page

19 / 26

Date Sign

Contents

FANUC Power Mate i-MODEL D/H

High Speed Position Switch

specifications

B-63173EN-1/01-31
